Air-Cooled Constant Temperature Gas Water Heater JSC-CT3W/B
Costant Temperature Forced Type
Configuration Parameter
零售价
市场价
重量
库存剩余
隐藏域元素占位
Highlights
Technical Specifications
Application
Unlike traditional water-cooled combustion systems, Greaidea's air-cooled integrated double-layer combustion chamber uses airflow—not water—to manage heat. This design drastically improves heat concentration, enables higher energy conversion efficiency, and simplifies maintenance, making it ideal for modern households users seeking eco-friendly and low-maintenance hot water solutions.
Color options: Elegant white or sleek gray
Precise Temperature Control By Al Algorithm
Achieve precise and consistent hot water with AI algorithm temperature control, a precision water flow sensor, dual-stage burner, double-speed variable-frequency fan, and a precision gas proportional valve—all working together for optimal performance and comfort.
Core Technology Highlight – Air-Cooled Double-Layer Combustion Chamber
Our advanced air-cooled, integrated double-layer closed combustion chamber is designed for maximum efficiency. By creating strong heat concentration within the sealed dual-layer structure, it ensures more complete combustion while reducing heat loss. This innovative design delivers powerful, stable heating with significantly improved energy savings.
Double Purification for Cleaner, Safer Water
Double purification is achieved through a Water Inlet Filter and Oxygen-Free Copper Pipe, effectively purifying water and inhibiting bacterial growth—providing cleaner, safer water that protects sensitive skin and enhances bathing comfort.
Advanced V-Shaped Burner for Efficient and Stable Performance
Equipped with a V-shaped variable frequency segmented burner, this system delivers concentrated flame for enhanced combustion efficiency. Intelligent gear shifting adapts to usage needs, ensuring stable firepower and optimized energy savings—ideal for clients seeking high-performance, customizable gas water heater solutions for competitive markets.
High-Efficiency Gas Water Heater for Competitive OEM Solutions
Delivering over 89% thermal efficiency and up to 80% gas savings, this advanced water heater is engineered for performance-focused brands. With a sleek digital interface and proven fuel economy, it's an ideal choice for clients seeking reliable, energy-efficient models for mass market or premium customization.
| Rated Water Output(△t=25℃)L/Min | 12L/min | 13L/min |
| Rated Thermal Load | 24KW | 26KW |
| Product Size(MM) Package Size(MM) | 560x350x140 685x405x215 | 560x350x140 685x405x215 |
| Loading Qty.(PCS)20FT/40FT/40HQ | 380/760/900 | 380/760/900 |
| Exhaust Way: | Forced Exhaust Type |
| Diameter of Smoke Exhaust: | Ф60MM |
| Ignition Mode: | Automatic Electrical Pulse Igniton |
| Gas Type: | LPG/Natural Gas |
| Rated Voltage: | AC 220V/50HZ &AC 110V/60HZ |
| Rated Water Pressure: | 0.01~0.8MPA |
| Connection Pipe Specs: | Water Inlet: G1/2" Pipe; Water Outlet:G1/2" Pipe; Gas Input: G1/2: Pipe |
